Digimat Material Model for Fiber Reinforced Plastics



Digimat is a material modeling platform for composites from MSC Software. It contains several modules for material modeling, fitting of parameters and coupling to FE structural solvers and process simulation software. It is particularly suitable for modeling of fiber reinforced plastics in LS-DYNA simulations. Local material properties depending on the fiber orientation will be achieved through the micromechanical models of Digimat. The modeling concepts of Digimat, the different modules and practical use will be covered for some common analysis types.






Preliminary contents:

  1. Short Fiber Reinforced Plastics (SFRP) modeling in Digimat
    1. Modules of Digimat
    2. Material- and failure models for different applications:
      1. Strength
      2. Crash
      3. Digimat-MF exercise
    3. Calibration of material parameters
      1. Digimat-MX exercise
    4. Coupling to production process, mapping of orientation tensors
      1. Digimat-Map exercise
    5. Coupling to FE software
      1. Digimat-RP coupled Digimat/LS-DYNA exercise
  2. Shortly on Carbon Fiber Reinforced Plastics (CFRP) in Digimat
    1. Digimat-VA failure exercise



In co-operation with e-Xstream

Dates
Dates Duration/days Registration Referee Language Location Fee
26.11.2019
2 days Registration
Dr. M. Landervik
Gothenburg
10000 SEK
25.02.2020
2 days Registration
Dr. M. Landervik
Jönköping
10000 SEK

Lecturers

Dr. M. Landervik
Dr. M. Landervik
